- Generation Four (G4) Digital Control Module – Large, 4.3" touch screen. Icon-driven interface streamlines operation
- On-Screen Instructions – Provides fast, intuitive training; reduces service calls
- Built-In Self Diagnostic System
- Energy Saving Mode
- Gold Cup Series™ – Programmable Time, Temperature, Volume, Pre-Infusion, Pulse-Brewing And Bypass
- Pre-Set, One-Touch Global Recipes – Based On Coffee Type, Grind And Weight. Simplifies Profile Setting For Gourmet Results Every Time
- Industry’s Most Effective Mineral Tolerant Design
- Patented Fast-Wetting AFS Sprayhead
- Non-Metallic Water Level Probe
- Non-Immersed Water Temperature Sensor
- Encapsulated Control Board – Protects Against Steam, Water And Impact
DIMENSIONS
| Height (in.) | 18.250" |
|---|---|
| Width (in.) | 13.250" |
| Depth (in.) | 21.000" |
| Cup Clearance (in.) | 6.88"" |
ELECTRICAL
| Phase | 1/1 |
|---|---|
| Volts | 120/220 |
| Amps | 12.5/10.8 |
| Heat Configuration | 2 x 1450W |
| Wire | 2W G/3W G |
| Watts | 1500/2379 |
| Hertz | 50/60 |
WATER
| Connector | 1/4" Flare |
|---|---|
| Pressure | 20 - 90 psi |
| Min. Flow Rate | 1.0 GPM |
| Tank Volume | 1.7 Gal. |
SHIPPING
| Ship Height (in.) | 23.00" |
|---|---|
| Ship Width (in.) | 16.00" |
| Ship Depth (in.) | 25.00" |
| Ship Weight | 34.00 lbs |
| Ship Cube | 5.32 cuft |
GENERAL
| Certification |
|
|---|---|
| Warning | Proposition 65 Warning — Applies to the State of California Only. Learn More > |
